PLANITHERM® ULTRA N/N II

PLANITHERM® ULTRA N/N II Thermally Insulating Glass

PLANITHERM® ULTRA N/N II is a higher performance, thermally insulating Low-Emissivity (Low-E) glass, as it achieves an emissivity level of >3%. It offers very good thermal insulation coupled with neutrality, and is positioned ideally for commercial applications. Manufactured in Britain, PLANITHERM® ULTRA N/N II can be toughened and is available in a range of thicknesses, providing versatility for various project requirements. Its key benefits include:

  • Thermal insulation performance, helping to reduce heating bills and eliminate cold areas around windows (see Calumen.com for product performances).
  • Neutral aesthetics that help the transmission of natural light into the building.
daylight comfort

Daylight

thermal insulation

Thermal insulation

energy efficient

Energy factors

Saint-Gobain Glass
saint-gobain glass
saint-gobain glass
saint-gobain glass

All images are for illustration purposes only

PLANITHERM® ULTRA N/N II Range

MONOLITHIC GLASS

  • Standard thicknesses: 6mm, 8mm and 10mm
  • Substrate: PLANICLEAR® clear float

TOUGHENED GLASS
PLANITHERM® ULTRA N/N II can be toughened to meet the safety glazing performance requirements of BS EN 12150. Critically, once toughened, this product has the same thermal performance and aesthetics as annealed PLANITHERM® ULTRA N.

LAMINATED GLASS
Available as STADIP®, STADIP® PROTECT laminated glass and STADIP® SILENCE acoustic laminated glass in most common configurations.

PLANITHERM® ULTRA N/N II LOW-E GLASS

SEALED UNIT MANUFACTURERS

  • It enables manufacturers to offer customers a low U-value glazing option for their windows or facades.
  • PLANITHERM® ULTRA N/N II is part of a family of PLANITHERM® coated glass products, each positioned to deliver performance for the relevant market, whether that’s domestic home improvement, new build, or commercial.

WINDOW OR FACADE FABRICATORS / INSTALLERS

  • PLANITHERM® ULTRA N/N II offers thermal insulation through its low centre pane U-value of 1.1W/m2.K*, while retaining neutral aesthetics (see Calumen.com for product performances).
  • Using sealed units with PLANITHERM® ULTRA N/N II can help windows and facades achieve low whole window U-values, to assist with compliance with the UK Building Regulations.

*4mm PLANICLEAR®/16mm cavity/90% argon/4mm PLANITHERM® ULTRA N/N II (face 3). Calculated using Calumen® III 1.27 23.04.2024.

END-USERS / CLIENTS

  • Low U-value can help reduce heating bills.
  • Low U-value can help reduce cold areas around windows.
  • High light transmission can help the transmission of natural light into the building.

See Calumen.com for product performances.

WHEN COMBINED WITH OTHER PRODUCTS
PLANITHERM® ULTRA N/N II thermally insulating glass can be combined with other Saint-Gobain Glass products, including:

  • COOL-LITE® Solar control coated glass
  • STADIP® SILENCE for noise reduction
  • STADIP® and STADIP® PROTECT for security
  • BIOCLEAN® self-clean glass for lower maintenance
  • Obscured, patterned, or decorative glass for privacy

PLANITHERM® ULTRA N/N II LOW-E GLASS Applications

PLANITHERM® ULTRA N/N II offers thermal insulation properties in combination with high neutrality. It is positioned for commercial exterior applications:

COMMERCIAL SOLUTIONS

  • Façades and windows
  • Structural glazing
  • Overhead glazing

RESIDENTIAL SOLUTIONS

  • Windows and skylights
  • Patio doors, French doors
  • Other external doors
  • Conservatories and sunrooms
